| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wired |
| PTZ modes | 4 Pattern, 8 Tour |
| PTZ protocols | Pelco-P/D, DH-SD |
| Tour recording | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Dynamic range | 120 dB |
| Certification | CE-EMC: EN 55032; EN 61000-3-3;
EN 61000-3-2; EN 50130-4; EN 55035
CE-LVD: EN 62368-1
FCC: 47 CFR FCC Part15, Subpart B, NSI C63.4 |
| Form factor | Bulb |
| Mounting type | Ceiling |
| Product colour | White |
| International Protection (IP) code | IP67 |
| IK code | IK10 |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Minimum illumination | 0.0005 lx |
| Angle of rotation | 180° |
| Lens viewing angle, horizontal | 58.5 - 2.8° |
| Lens viewing angle, vertical | 33.2 - 1.5° |
| Lens viewing angle, diagonal | 67.5 - 3.2° |
| Tilt angle range | 0 - 90° |
| Tilt speed | 250 °/sec |
| Tilt preset speed | 500 °/sec |
| Pan range | 0 - 360° |
| Pan speed | 350 °/sec |
| Pan preset speed | 500 °/sec |
| White balance | Auto, Indoor, Manual, Natural, Outdoor, Sodium lamp, Street lamp |
| Camera shutter type | Electronic |
| Camera shutter speed | 1/1 - 1/30000 s |
| Number of Privacy masking areas | 24 |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Progressive scan | Yes |
| Number of lenses | 1 |
| Optical zoom | 25x |
| Digital zoom | 16x |
| Detect distance | 1655.2 m |
| Observe distance | 653.8 m |
| Recognize distance | 331 m |
| Focal length range | 4.8 - 120 mm |
| Auto focus | Yes |
| Focus | Manual |
| Identify distance | 165.5 m |
| Focus adjustment | 1.6 - 3.5 |
| Closest focusing distance | 1 m |
| Night vision | No |
| Maximum resolution | 1920 x 1080 pixels |
| Total megapixels | 2 MP |
| Video compression formats | H.264, H.264B, H.264H, H.265, H.265+ |
| Supported graphics resolutions | 352 x 288, 640 x 480 (VGA), 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
| Supported video modes | 720p, 1080p |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Noise reduction | Yes |
| Noise reduction technology | 2D noise reduction, 3D noise reduction |
| Gain control type | Auto/Manual |
| Flip & mirror | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Bit rate | H.264: 2048 Kbps–8192 Kbps; H.265: 768 Kbps–6400 Kbps |
| Back Light Compensation (BLC) | Yes |
| Highlight Compensation (HLC) | Yes |
| Region of Interest (ROI) encoding | Yes |
| Audio input channels | 1.0 channels |
| Audio output channels | 1.0 channels |
| Audio formats supported | G.711 A-law, G.711 μ-law, G.722.1, G.723, G.726, PCM |
| Signal-to-Noise Ratio (SNR) | 55 dB |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Bluetooth | No |
| Supported network protocols | TCP; FTP; RTMP; IPv6;Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; IP Filter; SMB; HTTP; SSL; DHCP; SMTP; SNMPv1/v2c/v3(MIB-2); Qos; RTSP; ARP |
| Number of users | 20 user(s) |
| Streaming method | Multicast, Unicast |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 512 GB |
| Internal memory | 512 MB |
| ROM capacity | 128 MB |
| Ethernet LAN (RJ-45) ports | 1 |
| Video motion detection | Yes |
| Intelligent Video Surveillance (IVS) system features | Abandoned object, Face detection, Intrusion, Tripwire, Vehicle detection |
| Network access storage (NAS) | Yes |
| Web browser | Yes |
| Management software | DMSS; DSS Pro |
| Power source type | DC |
| DC output voltage | 24 |
| DC output current | 2.5 A |
| Operating temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Mobile operating systems supported | Android, iOS |
| Width | 186.2 mm |
| Height | 253 mm |
| Weight | 2.5 kg |
| Package weight | 4.5 kg |
| Number of cameras | 1 |
| Mounting kit | Yes |
| Mounting brackets included | Yes |
