AG NEOVO PM-3202 32IN FHD 350CD/QM 4000:1 5MS VGA HDMI LFD
|
|
AG NEOVO PM-3202 32IN FHD 350CD/QM 4000:1 5MS VGA HDMI LFD
-
Size
31.5"
-
Resolution
1920 x 1080
-
HD
Full HD
-
USB-C
0
-
DVI
0
-
DP
0
-
HDMI
3
-
Touchscreen
No
-
Speakers
Yes
-
Screen Shape
Flat
-
Height adjustment
No
-
Swivelling
No
-
Pivot
No
-
Usage
Infonäyttö
|
Description
Specifications
Energy label
Related products
PM-3202
32-Inch 1080P Slim Bezel Digital Signage Display
Features:
- Full HD 1920 x 1080 resolution
- 350 nits brightness for indoor public use
- Anti-Burn-in™ technology prevents image ghosting
- Built-in USB media playback signage content delivery
- Versatile connectivity: HDMI x 3, VGA
- Alink™ function for synchronised powering on/off via HDMI
- Extensive display control: RS232, LAN and PID Command & Ctrl software
- Black-level adjustment for presenting more details in dark images
- Selectable gamma curves optimise different kinds of images
- Ideal for 16/7 commercial operation
- HeatControl Sensors automatically reduce the screen brightness when temperature rises
Specifications:
- Panel
- Panel Type LED-Backlit TFT LCD (VA Technology)
- Panel Size 31.5"
- Max. Resolution FHD 1920 x 1080
- Pixel Pitch 0.364 mm
- Brightness 350 cd/m²
- Contrast Ratio 4000:1
- Viewing Angle (H/V) 178°/178°
- Display Colour 16.7M
- Response Time 5 ms
- Surface Treatment Anti-Glare Treatment (Haze 2%), 3H
- Frequency
- Frequency (H) 28 kHz-92 kHz
- Frequency (V) 48 Hz-85 Hz
- Signal Input
- HDMI 2.0 x 3
- VGA 15-Pin D-Sub x 1
- External Control
- IR Out 3.5 mm Phone Jack
- RS232 In
- LAN
- 9-Pin D-Sub
- RJ45 x 1
- Other Connectivity
- USB 2.0 x 1 (Service Port / Media Playback)
- Audio
- Audio In Stereo Audio Jack (3.5 mm)
- Audio Out Stereo Audio Jack (RCA)
- Internal Speakers 10W x 2
- Power
- Power Requirements AC 100-240V, 50/60 Hz
- On Mode 42W (On)
- Standby Mode < 0.5W
- Off Mode < 0.3W
- Power Supply Internal
- Operating Conditions
- Temperature 0°C-40°C (32°F-104°F)
- Humidity 20%-80% (non-condensing)
- Storage Conditions
- Temperature -20°C-60°C (-4°F-140°F)
- Humidity 10%-90% (non-condensing)
- Mounting
- VESA FPMPMI Yes (100 x 100 & 200 x 200 mm) Yes
- Security
- Dimensions
- Product w/o Base (W x H x D) 726.5 x 425.4 x 65.1 mm (28.6" x 16.8" x 2.6")
- Packaging (W x H x D) 818.0 x547.0 x 139.0 mm (32.2 x 21.5" x 5.5")
- Weight
- Product w/o Base 5.7 kg (12.6 lb)
- Packaging 7.8 kg (17.2 lb)
- Regulation Approval
- Certifications & Compliance FCC, CE, LVD, UKCA, WEEE, RoHS, REACH, EAC, ICES-003 (Issue 7)
- Accessories
- Supplied Power Cord, HDMI Cable, Remote Control, Batteries, Quick Start Guide
- Optional Accessories
- Ceiling Mount (Landscape only) CMP-01 + LMK-02, CMP-01 + WMK-03
- Wall Mount (Landscape only) LMA-01, LMA-02, LMK-02, WMA-01, WMK-03
- Desk Mount (Landscape only) DMC-01, ES-02
| Display diagonal | 80 cm (31.5") |
| Display technology | LCD |
| Panel type | VA |
| LED backlight | Yes |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 350 cd/m² |
| HD type | Full HD |
| Touchscreen | No |
| Response time | 5 ms |
| Contrast ratio (typical) | 4000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.7 million colours |
| Pixel pitch | 0.364 x 0.364 mm |
| Horizontal scan range | 28 - 92 kHz |
| Vertical scan range | 48 - 85 Hz |
| Haze rate | 2% |
| Surface hardness | 3H |
| HDMI ports quantity | 3 |
| HDMI version | 2.0 |
| HDMI input ports quantity | 3 |
| DVI port | No |
| VGA (D-Sub) input ports | 1 |
| DisplayPorts quantity | 0 |
| USB port | Yes |
| USB ports quantity | 1 |
| USB version | 2.0 |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wi-Fi | No |
| Audio (L/R) out | 1 |
| PC Audio in | Yes |
| Microphone in | Yes |
| RS-232 interface | Yes |
| Remote (IR) output | 1 |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| RMS rated power | 20 W |
| Product design | Digital signage flat panel |
| Product colour | Black |
| Placement supported | Indoor |
| Orientation | Vertical |
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100,200 x 200 mm |
| Anti-glare screen | Yes |
| Purpose | Universal |
| On Screen Display (OSD) | Yes |
| Operating hours (hours/days) | 16/7 |
| Power consumption (typical) | 42 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| Energy efficiency class (SDR) | G |
| Energy consumption (SDR) per 1000 hours | 42 kWh |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Computer system | No |
| Built-in processor | No |
| Display width | 726.5 mm |
| Display depth | 65.1 mm |
| Display height | 425.4 mm |
| Display weight | 5.7 kg |
| Package width | 818 mm |
| Package depth | 139 mm |
| Package height | 547 mm |
| Package weight | 7.8 kg |
| Remote control included | Yes |
| Batteries included | Yes |
| Power adapter included | Yes |
| Cables included | AC, HDMI |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Certification | FCC, CE, LVD, UKCA, WEEE, RoHS, REACH, EAC, ICES-003 (Issue 7) |
| Noise reduction | Yes |
| Quick start guide | Yes |
| RS-232 input ports | 1 |
